Gay 90's

Manufacturer: Williams Electronics, Incorporated (1967-1985) [Trade Name: Williams]
Year: 1970
Date: January 05, 1970
Type: Electro-mechanical (EM)
Players: 4
Production: 3,127 units (confirmed)

About This Machine

The Gay 90 is a significant addition to any pinball collection, offering a glimpse into the early days of electromechanical (EM) pinball design. As one of Steve Kordek's designs for Williams Electronics, this machine showcases the innovative spirit of its era. Released in 1970, the Gay 90 was part of a wave of EM machines that paved the way for the more complex solid-state games to come.

In terms of gameplay, the Gay 90 boasts a mix of traditional features and unique elements. Players can enjoy three or five ball play, with up to 9,999 points possible per player. The machine's layout is well-balanced, featuring two flippers, three pop bumpers, passive bumpers, slingshots, drop targets, and even a swinging target that adds an extra layer of challenge. A notable aspect of the Gay 90 is its sound design, which features two bells and a knocker to create an immersive experience.

The machine's historical theme is also noteworthy, transporting players back to America in the late 19th century. The artwork and decorations are a charming representation of this era, complete with vintage-style illustrations and typography. Interestingly, little information has been found about the Gay 90, making it all the more intriguing for collectors and enthusiasts looking to uncover its secrets.

Images (63)

Technical Details

Theme:
American 1890's - Historical
Model Number:
367
Notable Features:
Flippers (2), Pop bumpers (3), Passive bumpers (2), Slingshots (2), Drop targets (2), Kick-out hole (1), Swinging target (1), Left drop lane, Left kickback outlane, Right outlane ball return gate, Up-post between flippers. 3 or 5 ball play. Maximum displayed point score is 9,999 points per player. Replay wheel maximum: 37 Sound: 2 bells, knocker.

Credits

Designer:
Steve Kordek
Artist:
Christian Marche

Documentation

  • Catalog Supplement "T" With New Parts & Units
    1018 KB
    Download
  • Instruction Manual
    10 MB
    Download
  • Schematic Diagram (continuous)
    445 KB
    Download

Other Files

  • Promotional Photo - Large Size
    1 MB
    Download
