Dracula

Manufacturer: Stern Electronics, Incorporated, of Chicago, Illinois, USA (1977-1984) [Trade Name: Stern]
Year: 1979
Date: January, 1979
Type: Solid State Electronic (SS)
Players: 4
Production: 3,350 units (confirmed)

About This Machine

Meet Dracula, a hauntingly themed pinball machine released by Stern Electronics in January 1979. Designed by pinball pioneer Harry Williams, this four-player solid-state game (model 109, running on Stern's M-100 MPU) takes on a supernatural vampire theme, with 3,350 full games produced along with 262 knock-down games assembled in Australia under license as LAI's 1979 'Dracula'.

The playfield offers plenty for players to shoot at: three flippers, three pop bumpers, a passive bumper, two slingshots, five standup targets, five star rollovers, a 4-bank and a 3-bank of drop targets, a kick-out hole, a spinning target, and a horseshoe lane. The variety of targets and the extra third flipper give the game a busy, shot-rich layout typical of Stern's late-1970s output.

An interesting technical footnote: according to Stern's Service Bulletin #7A, Dracula uses the same ROMs as Stern's 1978 'Wild Fyre'. Dracula remains a solid example of Stern's early solid-state era, pairing a classic horror theme with the work of one of pinball's most storied designers.

Images (16)

Technical Details

Theme:
Fictional - Supernatural
Model Number:
109
MPU:
Stern M-100 MPU
Notable Features:
Flippers (3), Pop bumpers (3), Passive bumper (1), Slingshots (2), Standup targets (5), Star rollovers (5), 4-bank drop targets (1), 3-bank drop targets (1), Kick-out hole (1), Spinning target (1), Horseshoe lane (1).

Credits

Designer:
Harry Williams

ROM Files

Documentation

  • English Manual (no schematics)
    4 MB
    Download
  • Schematic Diagrams (paginated)
    14 MB
    Download

Service Bulletins

  • Service Bulletin #11 - Bookkeeping Errors Due to Power Switch Toggling (undated)
    12 MB
    Download
  • Service Bulletin #7A - R OM Sets (October 16, 1978)
    11 MB
    Download

Other Files

  • Engineering Bulletin #9 - Momentary Coil Information Q1 to 14 & Q16 (undated)
    12 MB
    Download
