Shamrock
About This Machine
The Shamrock pinball machine, manufactured by Industria (Electromecânica) de Recreativos S.A. of Madrid, Spain, is a rare and intriguing piece of electro-mechanical pinball history from 1977. As one of the lesser-known machines from this period, it offers a glimpse into the development of early pinball designs and the evolution of gameplay mechanics.
The Shamrock features a unique blend of classic elements, including two flippers, two pop bumpers, slingshots, standup targets, captive balls, kick-out holes, and an upper right kicker lane. The machine allows for either 3 or 5-ball play on its plexiglas playfield, setting it apart from many other pinball machines of the time. Notably, the Shamrock's logic is controlled by two-coil latching relays, a design choice that reduced energy consumption and coil abrasion but added significant weight to the machine.
The Shamrock's theme, Playing Cards, adds an interesting twist to its gameplay and art. While no information on the designer or artist is available, the combination of classic pinball elements with this unique theme makes it a fascinating piece for collectors and enthusiasts. Its scarcity and distinct design make the Shamrock a valuable discovery for those seeking to learn more about the early days of pinball history.
Images (18)
Technical Details
- Theme:
- Playing Cards
- Notable Features:
- Flippers (2), Pop bumpers (2), Slingshots (2), Standup targets (5), Captive balls (4), Kick-out holes (4), Upper right kicker lane. 3 or 5 ball play. Plexiglas playfield. Replay wheel maximum: 25 Sound: 1 bell, 3 chimes, knocker. The logic is almost entirely controlled by two-coil latching relays instead of using single coils that stay energized, thus adding weight to the machine (more coils used, machine is very heavy), but reducing energy consumption and coil abrasion.
Credits
Documentation
- DownloadSchematic Diagram (continuous)76 MB
