Boomerang

Manufacturer: Bally Manufacturing Corporation (1931-1983) [Trade Name: Bally]
Year: 1974
Date: December, 1974
Type: Electro-mechanical (EM)
Players: 4
Production: 2,585 units (confirmed)

About This Machine

The Bally Boomerang (1974) is a well-regarded electro-mechanical pinball machine that embodies a spirit of adventure and cultural exploration. Designed by Jim Patla with artwork by Christian Marche, this four-player game was released in December 1974, with a confirmed production run of 2,585 units. Interestingly, the 2-player version of this design appeared as Bally's 1975 'Flicker', with different artwork.

The Boomerang boasts an impressive array of features, including two flippers, a single pop bumper, two slingshots, 12 standup targets, eight star rollovers, two captive balls, a spinning target, a kick-out hole, and an action ring. An end-of-ball bonus rewards skilled play, and the maximum displayed point score is 199,990 points per player. The sound package consists of three chimes, typical of the era.

Marche's colorful, vibrant artwork transports players to far-off lands in keeping with the game's foreign-peoples adventure theme. With its packed playfield and classic mid-1970s Bally construction, the Boomerang remains an appealing find for collectors and enthusiasts of the late electro-mechanical era.

Images (18)

Technical Details

Theme:
Adventure - Foreign Peoples
Model Number:
1018
Notable Features:
Flippers (2), Pop bumper (1), Slingshots (2), Standup targets (12), Star rollovers (8), Captive balls (2), Spinning target (1), Kick-out hole (1), Action ring. End-of-ball bonus. Maximum displayed point score is 199,990 points per player. Sound: 3 chimes

Credits

Designer:
Jim Patla
Artist:
Christian Marche

Documentation

  • Playfield Chart from 1976 Parts Catalog
    653 KB
    Download
  • Schematic Diagram (continuous)
    2 MB
    Download

Other Files

  • 2 & 3 Coin Per Play Alternator Assemblies
    25 KB
    Download
  • Coin Chute Circuits
    96 KB
    Download
  • Installation And General Game Operation Instructions (original issue)
    5 MB
    Download
  • Installation And General Game Operation Instructions (undated reissue)
    400 KB
    Download
  • New Coil Numbers (Dated Jan 6, 1971)
    48 KB
    Download
  • Time Delay Circuit
    29 KB
    Download
  • Warranty
    307 KB
    Download
  • Wiring Diagram Correction
    14 KB
    Download
