Champion

Manufacturer: Bally Manufacturing Corporation (1931-1983) [Trade Name: Bally]
Type: Electro-mechanical (EM)
Players: 1

About This Machine

The Champion pinball machine, manufactured by Bally Manufacturing Corporation as Model 519, is a one-ball, single-player electro-mechanical (EM) horse-racing game. Its exact year of production is not documented, though it fits within the era of Bally's horse-racing and payout-style one-ball machines; the payout version of this game is Bally's 1949 Kentucky.

Key to the Champion's gameplay is its use of 31 trap holes and four passive bumpers, which provided players with various opportunities for scoring. The inclusion of a skill lane option for five-ball jurisdictions further adds to the machine's complexity and appeal to different operating regions. Notably, the game operates on a single ball for just five cents, making it an affordable and accessible experience for players.

The Champion's design and art are characteristic of early Bally one-ball machines, though specific details about its designer or artwork are unknown. It remains a piece of pinball history connected to Bally's broader run of horse-racing themed games.

Images (20)

Technical Details

Theme:
Sports - Horse Racing
Model Number:
519
Notable Features:
1 ball for 5 cents. Trap holes (31), Passive bumpers (4). Skill Lane option for 5-ball jurisdictions.

Credits

Documentation

  • Operating Instructions (bleached, long pages edited for printing, and includes the separate Parts Catalog)
    7 MB
    Download
  • Schematic Diagram (continuous)
    8 MB
    Download
  • Schematic Diagram (continuous, bleached)
    3 MB
    Download

Other Files

  • Engineering Drawing "400 To 1 Unit" (dated 7-19-49)
    916 KB
    Download
  • Operating Instructions (contains original full-length pages)
    18 MB
    Download
  • Switch Chart for "400 To 1 Unit"
    4 MB
    Download
