Stingray
About This Machine
The Stingray, manufactured by Stern Electronics and released in December 1977, was an early solid-state pinball machine from the newly formed Stern company, carrying a Scuba Diving / Water Sports theme.
The Stingray's gameplay features are both challenging and rewarding. Players navigate three or five balls through a course filled with obstacles, including two flippers, three pop bumpers, two slingshots, and three standup targets. The 5-bank drop target is a notable feature, offering players multiple shot options to reach the highest score. The sound package, with four bells and a knocker, adds to the experience.
Stingray was designed by Roger Sharpe and Sam Stern, with Mike Kubin building the whitewood prototype. It was one of two 4-player Stern games with a switch to convert to 2-player operation (the other being Stars, the game that followed it in production). Stern produced 3,006 confirmed units of Stingray between December 1977 and March 1978.
Images (29)
Technical Details
- Theme:
- Scuba Diving - Water Sports
- Model Number:
- 102
- MPU:
- Stern M-100 MPU
- Notable Features:
- Flippers (2), Pop bumpers (3), Slingshots (2), 5-bank drop targets (1), Standup targets (3), Kick-out holes (2), Spinning target (1). 3 or 5 ball play. Sound: 4 bells, knocker.
Credits
- Designer:
- Roger Sharpe, Sam Stern, Mike Kubin
Documentation
- DownloadDrop Target Bank D-393 (parts list and drawing)2 MB
- DownloadEnglish Manual (undated, CPU SW 25 not referenced on page 9, no schematics)10 MB
- DownloadEnglish Manual (undated, CPU SW 25 referenced on page 10, no schematics)719 KB
- DownloadMPU Control Board Schematic (dated 9-22-77)6 MB
- DownloadPlayfield Parts Diagram (includes a rubber ring chart)178 KB
- DownloadSchematic Diagrams (paginated but not split into halves)11 MB
- DownloadSchematic Diagrams (paginated, split into halves)691 KB
