Phoenix

Manufacturer: Williams Electronics, Incorporated (1967-1985) [Trade Name: Williams]
Year: 1978
Date: August 25, 1978
Type: Solid State Electronic (SS)
Players: 4
Production: 6,198 units (confirmed)

About This Machine

The Williams Phoenix, designed by Barry Oursler and released in August 1978, is a solid-state (SS) pinball machine built on the Williams System 4 platform, part of the industry's broader shift away from electromechanical (EM) designs during the late 1970s.

The Phoenix boasts an impressive array of features that cater to skilled players. Two flippers provide ample opportunities for precise control, while three pop bumpers add an extra layer of excitement to gameplay. The machine's drop targets are strategically placed to challenge players at various stages of the game, with two 4-bank targets and two single-drop targets offering distinct challenges. A spinning target at the top of a wire-form ramp adds a thrilling element of unpredictability.

The Phoenix's design is characterized by clean lines, minimal ornamentation, and a focus on functional simplicity. While its theme is not explicitly stated, the game's artwork features stylized, abstract shapes that add visual interest without detracting from gameplay. Interestingly, the machine's maximum displayed point score is 999,990 points per player, reflecting the growing emphasis on high scores in competitive pinball culture during this era.

Images (35)

Technical Details

Model Number:
485
MPU:
Williams System 4
Notable Features:
Flippers (2), Pop bumpers (3), 4-bank drop targets (2), Single drop targets (2), Standup targets (3), Spinning target (1). One target is at the top of a wireform ramp. Maximum displayed point score is 999,990 points per player.

Credits

Designer:
Barry Oursler
Artist:
Constantino Mitchell, Jeanine Mitchell
Software:
Paul Dussault
Sound:
Paul Dussault

ROM Files

Documentation

  • Catalog Supplement 485 With New Parts & Assemblies First Used On Phoenix
    2 MB
    Download
  • Driver Board Assembly Schematic (redrawn as Revision C dated 8-16-77)
    3 MB
    Download
  • Game Manual (October, 1978)
    4 MB
    Download
  • Instruction Cards, Score Cards, and Packing Notices
    2 MB
    Download
  • Schematics (paginated)
    36 MB
    Download

Other Files

  • B-7894 New Jet Style Bumper Assembly
    122 KB
    Download
  • Electronic Components & Complete Assemblies Used On Phoenix (January 1979)
    12 MB
    Download
  • sound PROM 512x8
    1 KB
    Download
