Motordome

Manufacturer: Bally Midway Manufacturing Company (1983-1988) [Trade Name: Bally]
Year: 1986
Date: June, 1986
Type: Solid State Electronic (SS)
Players: 4
Production: 2,000 units (confirmed)

About This Machine

The Motordome, designed by Greg Kmiec and manufactured by Bally in June 1986, is a solid-state electronic pinball machine built around the high-octane spirit of motocross racing. Produced in a run of 2,000 confirmed units, it stands as one of the more distinctive sports-themed machines of Bally's mid-1980s lineup.

The machine boasts an array of features: four flippers, three pop bumpers, two slingshots, six standup targets, two kick-out holes, a spinning target, a drop target, and aerial ramps, along with outlane detour gates on both sides. A standout feature is its skill-level selection, allowing players to choose from three different difficulty levels before launching their first ball.

The Motordome's artwork, by Tony Ramunni, captures the energy of 1980s motorcycle racing with dynamic imagery befitting its theme. With software by Rehman Merchant, the game reflects the technical and artistic style of Bally's pinball output in the mid-1980s.

Images (27)

Technical Details

Theme:
Sports - Motorcycles/Motocross
Model Number:
0E14
MPU:
Bally MPU A084-91786-AH06 (6803)
Notable Features:
Flippers (4), Pop bumpers (3), Slingshots (2), Standup targets (6), Kick-out holes (2), Spinning target (1), Drop target (1), Aerial ramps, Left outlane detour gate, Right outlane detour gate. Player selects one of three different skill levels before shooting first ball.

Credits

Designer:
Greg Kmiec
Artist:
Tony Ramunni
Software:
Rehman Merchant

ROM Files

Documentation

  • Bright Lights Field Kit Instructions (undated; schematic is dated 10/27/86)
    154 KB
    Download
  • Operating Manual (English, both Sections 1 and 2, low-res paginated schematics)
    4 MB
    Download
  • Operating Manual (English, Section 1 only, no schematics)
    766 KB
    Download
  • Operating Manual (English, Section 2 only, hi-res paginated schematics)
    11 MB
    Download
  • Parts Manual
    1 MB
    Download
  • Service Bulletin (August 11, 1986, Manual Error Correction)
    109 KB
    Download
  • Service Bulletin (June 26, 1986, Manual Error Corrections)
    354 KB
    Download
  • Service Handbook (German, paginated schematics)
    4 MB
    Download

Service Bulletins

  • Service Bulletin (June 26, 1986, transporting games with circular lamp)
    147 KB
    Download
  • Service Bulletin (Nov 14, 1986, Brite-Lite Field Kit for Distributors)
    305 KB
    Download

Other Files

  • Instruction Card and Skill Level Chart
    117 KB
    Download
