King Pin

Manufacturer: Williams Electronic Manufacturing Corporation (1958-1967) [Trade Name: Williams]
Year: 1962
Date: September 07, 1962
Type: Electro-mechanical (EM)
Players: 1
Production: 1,250 units (confirmed)

About This Machine

The King Pin, designed by Norm Clark and manufactured by Williams in 1962, is a significant addition to any serious pinball collection. It was Norm Clark's first game designed for Williams, and its bowling theme places it firmly within the classic era of electro-mechanical (EM) pinball.

Gameplay-wise, the King Pin boasts an array of unique features that set it apart from its contemporaries. Its four flippers and three pop bumpers offer a dynamic experience, while the two gobble holes and standup targets add an extra layer of challenge. The kicker mechanism provides an additional way to manipulate the ball's trajectory, making each play feel distinct. A notable aspect is the playfield's 10 rollover buttons arranged in the shape of bowling pins, echoing the game's sports theme.

Aesthetically, the King Pin features a reverse wedge head, characteristic of Williams' design style during this period. The machine's sports-themed artwork, centered around the sport of bowling, adds to its charm and nostalgic appeal. With a maximum replay wheel count of 47, collectors will appreciate the challenge and satisfaction of achieving high scores on this vintage gem.

Images (14)

Technical Details

Theme:
Sports - Bowling
Model Number:
271
Notable Features:
Flippers (4), Pop bumpers (3), Gobble holes (2), Standup targets (2), Kicker (1). Playfield has 10 rollover buttons arranged like a set of bowling pins. Reverse wedge head. Replay wheel maximum: 47
